Part #A952V080BU4SAA
MFG #A952V080BU4SAA
Product Description
17-1/2" x 28-3/4" x 34", 80000 BTU/Hr, 4 Ton, 120 VAC 60 Hz 1-Phase, 8 A FLA, 3/4 HP, 96% AFUE, ECM Motor, 2-Stage, Condensing, Direct/Non-Direct Vent, Serial Controlled, Variable Speed, Upflow/Horizontal Left/Right, Standard System, Natural Gas Furnace
Part #A952V080BU4SAA
MFG #A952V080BU4SAA
Product Description
17-1/2" x 28-3/4" x 34", 80000 BTU/Hr, 4 Ton, 120 VAC 60 Hz 1-Phase, 8 A FLA, 3/4 HP, 96% AFUE, ECM Motor, 2-Stage, Condensing, Direct/Non-Direct Vent, Serial Controlled, Variable Speed, Upflow/Horizontal Left/Right, Standard System, Natural Gas Furnace
- Stainless Steel Primary and Secondary Heat Exchangers; 34 Inch Cabinet Height on All Models; Variable Speed (ECM) Motor; Energy Star® Rated
- Gas Furnace; Type 2-Stage, Condensing, Direct/Non-Direct Vent, Serial Controlled, Variable Speed, Upflow/Horizontal Left/Right, Standard System; Btu per Hour 52000 (Input)/50440 (Output) 1-Stage, 80000 (Input)/77600 (Output) 2-Stage; Capacity 1207 to 1420 CFM at 0.1 Inch WG (Heating), 1800 to 1160 CFM at 0.1 Inch WG (Cooling); Size 17-1/2 Inch Width x 28-3/4 Inch Depth x 34 Inch Height; Vent Size 2 Inch Diameter; Inclusion/Features Direct Drive Blower, High Velocity Filter, Centrifugal Combustion Fan, Multi-Port Inshot Burner, 120 Volt Silicon Nitride Igniter Pilot Safety Device, 20 Gauge 409 Stainless Steel Heat Exchanger, Steel Cabinet; Voltage Rating 120 Volt AC 60 Hertz 1-Phase; Current Rating 8 Amp FLA (Blower Drive), 0.66 Amp FLA (Combustion Fan), 15 Amp (MOP); Motor Power Rating 3/4 HP (Blower Drive); Nominal Cooling Capacity 4 Ton; Motor Type ECM; Fuel Type Natural Gas; Blower Dimension 11 Inch Diameter x 8 Inch Width; Motor Speed Rating 3300/2600 RPM (Combustion Fan); Number of Burner 4; Pipe Connection Size 1/2 Inch; AFUE Rating 96 Percent (Condensing); Temperature Rating 35 to 65 Deg F; Applicable Standard ETL (Canada and US), ANSI Z21.47/CSA 2.3
- Brand
AMERICAN STANDARD
BTU Input80k
Capacity1207 to 1420 CFM at 0.1 Inch WG (Heating), 1800 to 1160 CFM at 0.1 Inch WG (Cooling)
Efficiency90% +
FamilyA952V-VS
OrientationUpflow
Size17-1/2 Inch Width x 28-3/4 Inch Depth x 34 Inch Height
Type2-Stage, Condensing, Direct/Non-Direct Vent, Serial Controlled, Variable Speed, Upflow/Horizontal Left/Right, Standard System
Vent Size2 Inch Diameter
